The latest Intel CPUs
The RS300-E8-RS4 is ready for new-generation Intel Xeon 22nm processors, which deliver a significant performance improvement over previous-generation processors in virtualization support, integrated security, scalability, and I/O performance. They assure frustration-free smooth operation.
2+1 expandability in UP 1U
The RS300-E8-RS4 ships with 2+1 expansion slots in a 1U system for higher expandability and better data protection. It has one PCI Express 3.0 x16 slot and one PCI Express 3.0 x8 slot to accommodate the power of two dual full-height add-on cards. An extra slot is reserved for optional ASUS PIKE cards for cost effective upgrades to SAS storage and RAID protection.
Better networking with new quad server-grade Intel I210 Ethernet
Four server-grade Intel Ethernet ports with the I210 controller double queuing capacity compared to previous-generation Intel Ethernet 82574L controllers, powering faster data transmission. In addition, quad LAN teaming ports provide high networking bandwidth with load balance and fault tolerance functions, which reduce data processing bottlenecks in virtualization environments by increasing virtualized traffic.
Best-in-class power efficiency and stability
With new ASUS Beat Thermal Choke technology, operating temperatures drop by as much as 5 degrees centigrade, helping ensure the lowest energy loss and up to 91% (VR) efficiency. The RS300-E8-RS4 is able to work stably under high ambient temperature environments of up to a sustained 40 degrees centigrade. It also includes 1+1 80 PLUS Gold power supplies to reduce power loss and power consumption, helping consumers save on total cost of ownership.
Processor / System Bus
1 x Socket LGA1150
Intel Xeon processor E3-1200 v3 product family
Generation
E8
Core Logic
Intel C224 Chipset
Memory
Total Slots : 4 (2-channel)
Capacity : Maximum up to 32GB UDIMM
Memory Type :DDR3 1600/1333 UDIMM
Expansion Slots
1 x PCI-E x16 (Gen3 x8 link) (Full-Height/HL)
1 x PCI-E x8 (Gen3 x4 link) (Full-Height/HL)
1x PIKE Slot for Stroage Enhancement
Storage
SATA Controller :
Intel C224
2 x SATA2 3Gb/s ports
4 x SATA3 6Gb/s ports
Intel Rapid Storage Technology Enterprise(RSTe) (For Windows Only)
(Support Software RAID 0, 1, 5, 10 )
LSI MegaRAID (For Linux/Windows)
(Support Software RAID 0, 1, 10 )
HDD Bays
4 x Hot-swap 3.5″ “HDD Bays
2 x SSD Bays(Optional)
Auxiliary Storage FDD/CD/DVD
Options: No Device
Networking
4 x Intel I210AT + 1 x Mgmt LAN
Graphic
Aspeed AST2300 with 32MB VRAM
On Board I/O
1 x PS/2 KB/MS port
5 x RJ-45 ports (One for ASMB7-iKVM)
4 x USB 3.0 ports (Front x 2, Rear x 2)
2 x USB 2.0 ports (Front x 0, Rear x 2)
1 x Internal A Type USB Port
2 x VGA port (Front x 1, Rear x 1)
OS Support
CentOS 5.8/6.3 64-bit
CentOS 5.8/6.2 64-bit
Windows Server 2012
Windows Server 2008 R2 Enterprise
Windows 8 32/64-bit
RedHat Enterprise Linux AS5.8/6.3 64-bit
x(Subject to change without any notice)
Management Solution
Software: ASWM Enterprise
Out of Band Remote Management: Optional ASMB7-iKVM for KVM-over-IP
Regulatory Compliance
BSMI, CCC, CE, C-Tick, FCC(Class A)
Form Factor
1U
Power Supply
1+1 Redundant 450W 80PLUS Gold Power Supply
Rating: 100-127Vac/200-240Vac,8A/4A ,47-63Hz, Class 1
Accessory Box
1 x RS300-E8 Users Guide
1 x ASUS ASWM Enterprise Users Guide
1 x Bag of Screws
2 x AC Power Cable
1 x ASUS Auto Installation DVD
1 x RS300-E8 Support DVD
1 x ASWM ENTERPRISE DVD
Item Dimension (L”xW”xH”):
30 x 23 x 8
Weight:
35 lb
Warranty Information:
NA
